Our strong rare earth magnets achieve magnetic energy products up to 52 MGOe (416 kJ/m³) and remanence up to 1.48T – 10 times stronger than standard ferrite magnets and 3 times stronger than samarium cobalt magnets of equivalent size. This extreme strength allows our clients to downsize their product designs by up to 40% without sacrificing performance, reducing material costs and improving energy efficiency in high-power applications like electric vehicle motors and wind turbine generators.
Products
strong rare earth magnets
Our strong rare earth magnets are engineered to deliver the highest magnetic strength available in permanent magnet technology, leveraging the unique properties of rare earth elements (neodymium, samarium, cobalt) to outperform traditional ferrite and alnico magnets by significant margins. As a fully integrated manufacturer with 30 years of expertise in rare earth magnetic materials, we produce these high-performance magnets from 95%+ purity virgin raw materials (no recycled content) using proprietary sintering and alloying processes that enhance magnetic energy product, temperature stability, and corrosion resistance. Unlike generic rare earth magnets on the market, our strong rare earth magnets undergo rigorous multi-stage quality control to ensure consistent performance, tight dimensional tolerances (±0.01mm), and compliance with international standards, making them the trusted choice for global manufacturers in automotive, renewable energy, aerospace, and medical device sectors.
Send Inquiry
Product Description
Strong Rare Earth Magnets: Unmatched Magnetic Performance for Industrial Innovation
Core Advantages of Our Strong Rare Earth Magnets
Exceptional Magnetic Strength-to-Size Ratio
Proprietary Rare Earth Alloy Formulation
We formulate our strong rare earth magnets with high-cost dysprosium iron alloy (not low-grade holmium iron) to enhance magnetic stability and reduce flux loss, particularly in high-temperature environments. This advanced alloying process ensures our neodymium-based strong rare earth magnets maintain 95% of their original magnetic strength for over 10 years of continuous use, while samarium cobalt variants withstand temperatures up to 350°C without performance degradation.
Precision Customization for Every Application
Our CNC machining centers produce strong rare earth magnets in nearly any shape – including blocks, discs, rings, arcs, and fully custom profiles – with sizes ranging from 0.2mm (ultra-thin precision components) to 300mm (large industrial magnets). Every strong rare earth magnet is finished with a uniform Ni-Cu-Ni triple-layer electroplating (5μm per layer) that passes 720-hour salt spray tests, providing exceptional corrosion resistance for marine, chemical, and outdoor applications. Custom coatings (Zn, Epoxy, Au) are also available for specialized requirements.
Technical Specifications of Strong Rare Earth Magnets
The table below outlines the standard grades and performance metrics for our two primary strong rare earth magnet systems: neodymium iron boron (NdFeB) for maximum strength, and samarium cobalt (SmCo) for extreme temperature resistance. Custom grades, sizes, and magnetization directions are available to meet your specific application needs, including high-corrosion, high-temperature, or precision assembly requirements.
| Material Type | Grade Range | Max Remanence (Br) mT | Magnetic Energy Product (BHmax) MGOe | Max Operating Temp (°C) | Key Applications |
|---|---|---|---|---|---|
| NdFeB Rare Earth Magnets | N30-N55 (M/H/SH/UH/EH/AH) | 1480 | 50-52 | 220 (AH Grade) | Electric vehicle motors, drone components, industrial pumps |
| SmCo 5 Rare Earth Magnets | SmCo 5, SmCo 5H | 1050 | 26-30 | 300 | Aerospace engines, high-temperature industrial equipment |
| SmCo 2:17 Rare Earth Magnets | SmCo 2:17, SmCo 2:17H | 1150 | 30-34 | 350 | Medical imaging equipment, nuclear power components |
Quality Assurance & Global Compliance for Strong Rare Earth Magnets
Every batch of strong rare earth magnets undergoes a rigorous 16-step quality inspection process to ensure compliance with international standards. Our quality lab uses X-ray fluorescence spectrometers to verify rare earth element purity and composition, digital gauss meters to test magnetic performance, and coordinate measuring machines (CMM) to validate dimensional accuracy. We maintain full traceability for every strong rare earth magnet, from raw material lot numbers to final shipping documentation, ensuring complete accountability for our global clients. Our strong rare earth magnets comply with IATF 16949 (automotive), ISO 9001, REACH, RoHS 2.0, California Prop 65, and EN71, enabling seamless export to Europe, North America, Asia-Pacific, and Latin American markets.
IATF 16949:2016 ISO 9001:2015 REACH Compliant RoHS 2.0 Certified SGS 300+ Tests Passed
Packaging & Flexible Delivery for Strong Rare Earth Magnets
Due to their extreme magnetic strength and sensitivity to damage, our strong rare earth magnets require specialized packaging to prevent magnetic interference, chipping, and demagnetization during transit. Each strong rare earth magnet is individually wrapped in magnetic-shielding anti-static film and placed in custom foam inserts within 8-cell reinforced plastic trays, then packed into export-grade corrugated cartons with additional magnetic shielding layers. We offer flexible delivery options: free sample shipments (5-10 standard strong rare earth magnets) with 3-5 day express delivery, small-batch production (1-2 weeks lead time), and mass production (2-4 weeks lead time) with payment terms including T/T, L/C, and PayPal to suit your business model.
Partner with Us for Custom Strong Rare Earth Magnet Solutions
Whether you need high-strength neodymium rare earth magnets, extreme-temperature samarium cobalt rare earth magnets, or fully customized magnetic solutions, our team of magnetic engineering experts provides free technical support – including magnetic circuit design, material selection, and sample testing. With 30 years of focus on advanced rare earth magnetic materials, we deliver strong rare earth magnets that balance unbeatable performance, precision, and reliability for your most critical industrial applications.
Contact us 24/7 via WhatsApp/WeChat/Tel: +86-18226620303 | Sample delivery: 3-5 business days
